ANDERSON NEGELE
Anderson Negele Pressure sensor DAN-HH
DAN-HH
We market high quality printing and design from our supplier Anderson-Negele, which meets the highest standards of process engineering, and is the perfect solution for applications for food, pharmaceuticals, breweries, cosmetics and pharmaceutical processes.
The products of Anderson-Negele are manufactured according to the concept "Hygienic by Design", which is reflected in the special process adapters: CLEANadapt and PHARMadapt as well as the unique design of the instruments.
Pressure sensor, type DAN-HH -...
This unit uses a built-in piezoelectric converter to convert the process value into a corresponding mV signal. The mV signal then passes through a customer-specific linearization and signal processing. The resulting signal corresponds to industry standard 4 ... 20 mA. This mA signal is factory-set for this unit's measurement range. For relative pressure sensors, the back of the membrane is ventilated; that is, this sensor measures the mean pressure and / or vacuum relative to air pressure.
For an absolute pressure sensor, the measured value is relative to a perfect theoretical vacuum. This means that the signal changes with the air pressure for the respective environment.
Other features:
· CIP / SIP cleaning up to 150 ° C
· Product-related materials are FDA-compatible
· Stainless steel sensor and product-related materials
· Additional process connections in combination with CLEANadapt: Flange (DIN 11851), VARIVENT, m.f.
Please contact us for more information and price.
- Pressure measurement in pipes and containers
- High temperatures up to 150 ° C
- Front-flush, hygienic and easily sterilizable installation with EMZ-352 or EHG -... / 1 "connection
- Complies with 3-A Sanitary Standard 74-06, Third Party Verified (Only with Tri-Clamp Mount)
- EHEDG-certified hygienic CLEANadapt process connection
Selected variant
Art:
Selected variant
Specifications
| Approvals | 3-A, FDA |
|---|---|
| Area of application | Food |
| IP Class | IP69K |
| Material of sensor housing | Stainless steel AISI 304 |
| Materials Wetted Parts | Stainless steel 316L |
| Measuring Range | 0 ... 34 bar rel., -1 ... 13 bar rel. / 0 ... 20 bar abs. |
| Supply Voltage DC Max | 36 |
| Supply Voltage DC Min | 12 |
|---|---|
| Surface Finish | 0.6 |
| Temperature ambient from | -20 |
| Temperature ambient to | 50 |
| Temperature range of media from | 0 |
| Temperature range of media to | 150 |
Downloads
Product description
We market high quality printing and design from our supplier Anderson-Negele, which meets the highest standards of process engineering, and is the perfect solution for applications for food, pharmaceuticals, breweries, cosmetics and pharmaceutical processes.
The products of Anderson-Negele are manufactured according to the concept "Hygienic by Design", which is reflected in the special process adapters: CLEANadapt and PHARMadapt as well as the unique design of the instruments.
Pressure sensor, type DAN-HH -...
This unit uses a built-in piezoelectric converter to convert the process value into a corresponding mV signal. The mV signal then passes through a customer-specific linearization and signal processing. The resulting signal corresponds to industry standard 4 ... 20 mA. This mA signal is factory-set for this unit's measurement range. For relative pressure sensors, the back of the membrane is ventilated; that is, this sensor measures the mean pressure and / or vacuum relative to air pressure.
For an absolute pressure sensor, the measured value is relative to a perfect theoretical vacuum. This means that the signal changes with the air pressure for the respective environment.
Other features:
· CIP / SIP cleaning up to 150 ° C
· Product-related materials are FDA-compatible
· Stainless steel sensor and product-related materials
· Additional process connections in combination with CLEANadapt: Flange (DIN 11851), VARIVENT, m.f.
Please contact us for more information and price.
Ordering information
Please refer to the image below for ordering information.
