Specifications
| Connection Air | 1/8 BSP |
|---|---|
| Connection Thread | 3/4 BSP |
| Current max | 0.15 |
| Differential Pressure Air Max | 10 |
| Differential Pressure Max | 10 |
| Differential Pressure Min | 0 |
| Differential Pressure Oil Max | 10 |
| Differential Pressure Water Max | 10 |
| Differential steam pressure max | 10 |
| Disc Material | Brass |
| Disc Sealing Material | PTFE, Stainless steel |
| Flow Factor / Flow Coefficient | 7,1 |
| Flow Max l/min Double | 118 |
| Function 1 | 2/2 |
| Function 2 | Normally Closed |
| IP Class | IP65 |
| Material Body | Bronze |
| Material of body | Bronze |
| Material Operator | Reinforced polyamide |
|---|---|
| Material Rod | Stainless steel |
| Materials Piston Rod Seal | PTFE |
| Max. pressure | 16 |
| Operating Voltage AC / DC Max | 24 |
| Pilot Pressure Max | 8 |
| Pilot Pressure Min | 4 |
| Power Consumption | 3.6 |
| Repeatability | <1 % |
| Temperature range from | 0 |
| Temperature range of media from | -10 |
| Temperature range of media to | 180 |
| Temperature range to | 50 |
| Throughput | 20 |
| Type of valve | Proportional valve |
| Viscosity Max | 600 |
