The type 2260 is a rugged, high performance ultrasonic level measurement transmitter, having transducer and processing electronics and a display/ programming unit incorporated in one single housing. All type 2260 Level Transmitters are using established high end pulse echo transducers, which provide narrow beam angles and reliable measurement ranges up to a distance of 15 meters.
For small, stand alone tanks the transmitter provides a simple 2-wire 4 to 20 mA output, with additional power relay contacts. It can be programmed using push buttons and the large, graphic display. For large and/or multiple tank applications versions with HART interface are recommended, communicating directly with a panel mount controller or PLC. The HART protocol can easily be used for programming these versions.
The type 2260 is a rugged, high performance ultrasonic level measurement transmitter, having transducer and processing electronics and a display/ programming unit incorporated in one single housing. All type 2260 Level Transmitters are using established high end pulse echo transducers, which provide narrow beam angles and reliable measurement ranges up to a distance of 15 meters.
For small, stand alone tanks the transmitter provides a simple 2-wire 4 to 20 mA output, with additional power relay contacts. It can be programmed using push buttons and the large, graphic display. For large and/or multiple tank applications versions with HART interface are recommended, communicating directly with a panel mount controller or PLC. The HART protocol can easily be used for programming these versions.
Accessories
My favourites
Articles
Price
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PP body, 4..20 mA 2-wire, 1 1/2 " BSP thread
Art:
2260-P-0DB-4
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PP body, 4..20 mA 2-wire / relay / HART, 1 1/2 BSP thread
Art:
2260-P-2DB-4
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PP body, 4..20 mA 2-wire, 2" BSP thread
Art:
2260-P-0DB-6
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PP body, 4..20 mA 2-wire / relay / HART, 2" BSP thread
Art:
2260-P-2DB-6
Copied
2260 Ultrasonic Level Sensor Display - Range 8 m / 1.1 to 26 ft, PP body, 4..20 mA 2-wire / relay / HART, 2" BSP thread
Art:
2260-P-0DB-8
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PP body, 4..20 mA 2-wire, DIN Flange DN125
Art:
2260-P-0DF-15
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PP body, 4..20 mA 2-wire / relay / HART, DIN Flange DN125
Art:
2260-P-2DF-15
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PP body, 4..20 mA 2-wire, 1 1/2 " NPT thread
Art:
2260-P-0DN-4
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PP body, 4..20 mA 2-wire / relay / HART, 1 1/2 NPT thread
Art:
2260-P-2DN-4
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PP body, 4..20 mA 2-wire, 2" NPT thread
Art:
2260-P-0DN-6
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PP body, 4..20 mA 2-wire / relay / HART, 2" NPT thread
Art:
2260-P-2DN-6
Copied
2260 Ultrasonic Level Sensor Display - Range 8 m / 1.1 to 26 ft, PP body, 4..20 mA 2-wire / relay / HART, 2" NPT thread
Art:
2260-P-0DN-8
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PP body, 4..20 mA 2-wire, ANSI Flange 5 inch
Art:
2260-P-0DA-15
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PP body, 4..20 mA 2-wire / relay / HART, ANSI Flange 5 inch
Art:
2260-P-2DA-15
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PVDF body, 4..20 mA 2-wire, 1 1/2 " BSP thread
Art:
2260-V-0DB-4
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PVDF body, 4..20 mA 2-wire / relay / HART, 1 1/2 BSP thread
Art:
2260-V-2DB-4
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PVDF body, 4..20 mA 2-wire, 2" BSP thread
Art:
2260-V-0DB-6
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PVDF body, 4..20 mA 2-wire / relay / HART, 2" BSP thread
Art:
2260-V-2DB-6
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PVDF body, 4..20 mA 2-wire, DIN Flange DN125
Art:
2260-V-0DF-15
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PVDF body, 4..20 mA 2-wire / relay / HART, DIN Flange DN125
Art:
2260-V-2DF-15
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PVDF body, 4..20 mA 2-wire, 1 1/2" NPT thread
Art:
2260-V-0DN-4
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PVDF body, 4..20 mA 2-wire / relay / HART,1 1/2" NPT thread
Art:
2260-V-2DN-4
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PVDF body, 4..20 mA 2-wire, 2" NPT thread
Art:
2260-V-0DN-6
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PVDF body, 4..20 mA 2-wire / relay / HART, 2" NPT thread
Art:
2260-V-2DN-6
Copied
2260 Ultrasonic Level Sensor Display - Range 8 m / 1.1 to 26 ft, P\VDF body, 4..20 mA 2-wire / relay / HART, 2" NPT thread
Art:
2260-V-0DN-8
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PVDF body, 4..20 mA 2-wire, ANSI Flange 5 inch
Art:
2260-V-0DA-15
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PVDF body, 4..20 mA 2-wire / relay / HART, ANSI Flange 5 inch
Art:
2260-V-2DA-15
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PVDF body, 4..20 mA 2-wire / HART, ATEX, 1 1/2" BSP thread
Art:
2260-V-1DBX-4
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PVDF body, 4..20 mA 2-wire / HART, ATEX, 2" BSP thread
Art:
2260-V-1DBX-6
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PVDF body, 4..20 mA 2-wire / HART, ATEX, Flange 5 inch
Art:
2260-V-1DFX-15
Copied
2260 Ultrasonic Level Sensor Display - Range 4 m / 0.65 to 13 ft, PVDF body, 4..20 mA 2-wire / HART, ATEX, 1 1/2" NPT thread
Art:
2260-V-1DNX-4
Copied
2260 Ultrasonic Level Sensor Display - Range 6 m / 0.82 to 20 ft, PVDF body, 4..20 mA 2-wire / HART, ATEX, 2" NPT thread
Art:
2260-V-1DNX-6
Copied
2260 Ultrasonic Level Sensor Display - Range 15 m / 1.5 to 49 ft, PVDF body, 4..20 mA 2-wire / HART, ATEX, ANSI Flange 5 inch
Art:
2260-V-1DAX-15
Copied
