Wika Hydraulic Load Cell F1106/F115/F1135/F1145

Compression Force Transducer up to 850 kN

Load cell in compact cylindrical design with integrated analog output signal, adapted to be placed under tanks or silos for weighing and indicating materials. To measure liquid level in tanks with three legs, this force transducer can be placed under one leg and measure 1/3 of the total mass.

  • Operates without power supply
  • Handles oblique forces up to 3°
  • Accuracy ≤±1.6%
  • Stainless steel pressure plate and piston
  • Piston movement ≤0.5mm

Selected variant

Avaible in several variants

Save as pdf

Technical data / Documents

Product description

Accessories & Related products

Selected variant

Specifications

Force range 0-16 kN
IP Class IP65
Nominal Operating 0.5
Temperature range from -10
Temperature range to 50

Downloads

Measurements and connections

Product description

Load cell in compact cylindrical design with integrated analog output signal, adapted to be placed under tanks or silos for weighing and indicating materials. To measure liquid level in tanks with three legs, this force transducer can be placed under one leg and measure 1/3 of the total mass.

Accessories

My favourites Articles Diameter Force range Price
136977_812.tif
Hydraulic force sensor, Ø75, 0-16 kN with Ø63 gauge
Art:
F11061416145 Copied
0-16 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-0.25 kN with Ø63 gauge
Art:
F11062225280 Copied
75
0-0,25 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-0.4 kN with Ø63 gauge
Art:
F11062240281 Copied
75
0-0,4 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-1 kN with Ø63 gauge
Art:
F11061310283 Copied
0-1 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-2 kN with Ø63 gauge
Art:
F11351320291 Copied
0-2 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-4 kN with Ø63 gauge
Art:
F11061340285 Copied
75
0-4 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-50 kN with Ø63 gauge
Art:
F11061460123 Copied
0-50 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-0.32 kN with Ø63 gauge
Art:
F11152231038 Copied
0-0,32 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-1.2 kN with Ø63 gauge
Art:
F11151312048 Copied
0-1,2 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-3.2 kN with Ø63 gauge
Art:
F11351332292 Copied
0-3,2 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-5 kN with Ø63 gauge
Art:
F11151350185 Copied
0-5 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-1.6 kN with Ø63 gauge
Art:
F11061316284 Copied
0-1,6 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-8 kN with Ø63 gauge
Art:
F11351380293 Copied
0-8 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-6 kN with Ø63 gauge
Art:
F11061360286 Copied
0-6 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-20 kN with Ø63 gauge
Art:
F11151420068 Copied
0-20 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-2 kN with Ø63 gauge
Art:
F11151320289 Copied
0-2 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-12 kN with Ø63 gauge
Art:
F11351412294 Copied
0-12 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-8 kN with Ø63 gauge
Art:
F11151380054 Copied
0-8 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-3.2 kN with Ø63 gauge
Art:
F11151332053 Copied
90
0-3,2 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-50 kN with Ø63 gauge
Art:
F11151450006 Copied
90
0-50 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-2.5 kN with Ø63 gauge
Art:
F11061325082 Copied
0-2,5 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-20 kN with Ø63 gauge
Art:
F11351420295 Copied
0-20 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-10 kN with Ø63 gauge
Art:
F11061410287 Copied
0-10 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-25 kN with Ø63 gauge
Art:
F11061425087 Copied
0-25 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-32 kN with Ø63 gauge
Art:
F11351432296 Copied
0-32 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-12 kN with Ø63 gauge
Art:
F11151412050 Copied
0-12 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-60 kN with Ø63 gauge
Art:
F11151460113 Copied
0-60 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-0.5 kN with Ø63 gauge
Art:
F11152250007 Copied
0-0,5 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-80 kN with Ø63 gauge
Art:
F11351480298 Copied
0-80 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-220 kN with Ø63 gauge
Art:
F11451522308 Copied
0-220 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-6 kN with Ø63 gauge
Art:
F11451360302 Copied
0-6 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-120 kN with Ø63 gauge
Art:
F11351512148 Copied
0-120 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-320 kN with Ø63 gauge
Art:
F11451535309 Copied
0-320 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-32 kN with Ø63 gauge
Art:
F11061432288 Copied
0-32 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-8 kN with Ø63 gauge
Art:
F11451380303 Copied
0-8 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-200 kN with Ø63 gauge
Art:
F11351520299 Copied
0-200 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-50 kN with Ø63 gauge
Art:
F11351450297 Copied
138
0-50 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-0.6 kN with Ø63 gauge
Art:
F11062260282 Copied
0-0,6 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-80 kN with Ø63 gauge
Art:
F11151480290 Copied
0-80 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-450 kN with Ø63 gauge
Art:
F11451545310 Copied
0-450 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-250 kN with Ø63 gauge
Art:
F11351525300 Copied
138
0-250 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-32 kN with Ø63 gauge
Art:
F11151432057 Copied
0-32 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-14 kN with Ø63 gauge
Art:
F11451414304 Copied
0-14 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-0.16 kN with Ø63 gauge
Art:
F11062216156 Copied
0-0,16 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-0.8 kN with Ø63 gauge
Art:
F11152280110 Copied
0-0,8 kN
136977_812.tif
Hydraulic force sensor, Ø138, 0-320 kN with Ø63 gauge
Art:
F11351532301 Copied
0-320 kN
136977_812.tif
Hydraulic force sensor, Ø90, 0-120 kN with Ø63 gauge
Art:
F11152220045 Copied
0-120 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-600 kN with Ø63 gauge
Art:
F11451560311 Copied
0-600 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-34 kN with Ø63 gauge
Art:
F11451434305 Copied
0-34 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-800 kN with Ø63 gauge
Art:
F11451580312 Copied
0-800 kN
136977_812.tif
Hydraulic force sensor, Ø75, 0-40 kN with Ø63 gauge
Art:
F11061440165 Copied
0-40 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-80 kN with Ø63 gauge
Art:
F11451480306 Copied
0-80 kN
136977_812.tif
Hydraulic force sensor, Ø145, 0-140 kN with Ø63 gauge
Art:
F11451514307 Copied
0-140 kN
