ADVANCED ILLUMINATION
Advanced Illumination - AL295 Microbrite
Compact Area Lighting
The AL295 is part of the Microbrite family of high performance, compact machine vision lights. Outperforming the competition with a high intensity output of 73 kLux at a working distance of 100mm. The AL295 is available is expandable sizes in 3" increments up to 18".
Power options include:
- C1 connector - for use with DCS series controllers
- C5 connector - for use with Pulsar 320 strobe controller
- Continuous in-line controller - powered by 24V power supply
- Combination strobe/continuous in-line controller - powered by 24V power supply
- Default-OFF strobe/continuous in-line controller - powered by 24V power supply
- Flying/tinned leads - powered by 24V power supply
Other Wavelength options:
- UV - 365, 375, 385, 395, 405
- Royal blue - 455
- Blue - 470
- Cyan - 505
- Green - 530
- Amber - 590
- Red orange - 625
- Red - 660
- Infrared - 730, 850, 940
- White - WHI
For enquiries or quotes for wavelength and power options not listed here please contact us.
- High-performance compact line light
- Available in 76 mm (3 inch) increments up to 457 mm (18 inches)
Selected variant
Selected variant
Specifications
| Approvals | IEC 62471, CE, RoHS |
|---|---|
| Color | Royal blue |
| Connector/controller | C5 connector |
| IP Class | IP50 |
| Length | 166 |
| Operating temperature | 0 - 60°C |
| Photobiological Risk Factor IEC 6247 | Group 2 (moderate risk) |
| Standard cable length | Up to 2 meters |
| Wave-Length | 455 |
| Weight | 68.9 |
| Width | 20 |
Product description
The AL295 is part of the Microbrite family of high performance, compact machine vision lights. Outperforming the competition with a high intensity output of 73 kLux at a working distance of 100mm. The AL295 is available is expandable sizes in 3" increments up to 18".
Power options include:
- C1 connector - for use with DCS series controllers
- C5 connector - for use with Pulsar 320 strobe controller
- Continuous in-line controller - powered by 24V power supply
- Combination strobe/continuous in-line controller - powered by 24V power supply
- Default-OFF strobe/continuous in-line controller - powered by 24V power supply
- Flying/tinned leads - powered by 24V power supply
Other Wavelength options:
- UV - 365, 375, 385, 395, 405
- Royal blue - 455
- Blue - 470
- Cyan - 505
- Green - 530
- Amber - 590
- Red orange - 625
- Red - 660
- Infrared - 730, 850, 940
- White - WHI
For enquiries or quotes for wavelength and power options not listed here please contact us.
