ADVANCED ILLUMINATION
Advanced Illumination - AL150 BALA lighting
Broad Area Linear Array
Designed for applications that require broad illumination over a wide area, or for applications requiring an even broader field of illumintion, utilise 2 BALA bar lights in parallel.
The AL150 bar light series is expandable in 1" increments up to 82".
Power options include:
- C1 connector - for use with DCS series controllers
- C5 connector - for use with Pulsar 320 strobe controller
- Continuous in-line controller - powered by 24V power supply
- Combination strobe/continuous in-line controller - powered by 24V power supply
- Default-OFF strobe/continuous in-line controller - powered by 24V power supply
- Flying/tinned leads - powered by 24V power supply
Other Wavelength options:
- UV - 395
- Blue - 470
- Green - 520
- Red - 625, 660
- Infrared - 880
- White - WHI
For enquiries or quotes for sizes and power options not listed here please contact us.
- Designed to handle a long, wide field with low angle of view
- Available in 25 mm (1 ") increments up to 80"
Selected variant
Selected variant
Specifications
| Approvals | IEC 62471, CE, RoHS |
|---|---|
| Color | Red |
| Connector/controller | Strobe/continuous in-line controller |
| IP Class | IP50 |
| Length | 41 |
| Number of LED | 6 |
| Operating temperature | 0°C - 60°C |
| Photobiological Risk Factor IEC 6247 | Group 1 (low risk) |
| Standard cable length | Up to 2 meters |
| Wave-Length | 660 |
| Width | 34 |
Downloads
Product description
Designed for applications that require broad illumination over a wide area, or for applications requiring an even broader field of illumintion, utilise 2 BALA bar lights in parallel.
The AL150 bar light series is expandable in 1" increments up to 82".
Power options include:
- C1 connector - for use with DCS series controllers
- C5 connector - for use with Pulsar 320 strobe controller
- Continuous in-line controller - powered by 24V power supply
- Combination strobe/continuous in-line controller - powered by 24V power supply
- Default-OFF strobe/continuous in-line controller - powered by 24V power supply
- Flying/tinned leads - powered by 24V power supply
Other Wavelength options:
- UV - 395
- Blue - 470
- Green - 520
- Red - 625, 660
- Infrared - 880
- White - WHI
For enquiries or quotes for sizes and power options not listed here please contact us.
