Advanced Illumination - CX Series Backlights
Expandable Side Lit Collimated
The CX series of backlights are expandable, available in 1” increments up to 16” X 16”.
Edge-lit collimated backlights are characterized by their high intensity and low heat output. These collimated backlights produce a distinct silhouette and can improve edge detection of curved objects.
Power options include:
- C1 connector - for use with DCS series controllers
- C5 connector - for use with Pulsar 320 strobe controller
- Continuous in-line controller - powered by 24V power supply
- Combination strobe/continuous in-line controller - powered by 24V power supply
- Default-OFF strobe/continuous in-line controller - powered by 24V power supply
For enquiries or quotes for sizes and power options not listed here please contact us.
- 30% brighter than same size surface mount light
- Uniform illumination and low heat output
- Available in 1” x 1” increments up to 16” x 16”.
Selected variant
Selected variant
Specifications
| Approvals | IEC 62471, CE, RoHS |
|---|---|
| Cable length | 101.6 |
| Color | Blue |
| Connector/controller | C1 connector |
| IP Class | IP50 |
| Operating temperature | 0°C - 60°C |
| Photobiological Risk Factor IEC 6247 | Group 1 (low risk) |
| Standard cable length | Up to 2 metres |
| Wave-Length | 455 |
| Weight | 561.6 |
| Width | 101.6 |
Downloads
Product description
The CX series of backlights are expandable, available in 1” increments up to 16” X 16”.
Edge-lit collimated backlights are characterized by their high intensity and low heat output. These collimated backlights produce a distinct silhouette and can improve edge detection of curved objects.
Power options include:
- C1 connector - for use with DCS series controllers
- C5 connector - for use with Pulsar 320 strobe controller
- Continuous in-line controller - powered by 24V power supply
- Combination strobe/continuous in-line controller - powered by 24V power supply
- Default-OFF strobe/continuous in-line controller - powered by 24V power supply
For enquiries or quotes for sizes and power options not listed here please contact us.
