IDEM
A coded magnetic switch made of small size stainless steel that is ideal for use in the food and pharmaceutical industries. The switch has a standard spacing of fixing holes - 22 mm and is resistant to pressure washing. Installation with hexagonal screws makes the circuit breaker more resistant to dirt and is therefore ideal for demanding food applications.
Approvals | ISO 14119, EN60947-5-1, EN60204-1, ISO 13849-1, EN62061, UL 508 |
---|---|
Cable length | 2 m |
Cable type | PVC 6 or 8 core 6mm OD conductors 0.25mm² |
Central Material | Stainless steel 316 |
Coding | Coded magnetic actuation |
Conductor size | 0.25 |
Contact rating max | 24Vdc 0.2A |
Contacts | 2NC |
Integrated LED indication | Yes |
IP Class | IP67, IP69K |
Mounting | 2 x M4 |
MTTFd | 866 years |
---|---|
Operating temperature | -25..105°C |
PFHd | 8.71 x 10⁻¹¹ |
PL | e acc. ISO13849-1 |
Recommended mounting gap | 5 |
SIL | 3 acc. EN62061 |
Switching current min | 10Vdc 1mA |
Switching distance | Sao 8mm close, Sar 12mm open |
Switching frequency max | 1.0Hz maximum |
A coded magnetic switch made of small size stainless steel that is ideal for use in the food and pharmaceutical industries. The switch has a standard spacing of fixing holes - 22 mm and is resistant to pressure washing. Installation with hexagonal screws makes the circuit breaker more resistant to dirt and is therefore ideal for demanding food applications.
Precise, Durable Linear Measurement from Kübler
Browse our range of Kübler draw wire encoders and linear measurement systems, designed for accurate position and speed sensing in industrial and OEM applications. Built for tough environments. Trusted by automation professionals.
In complex, high-stakes electrical environments, precision, safety, and performance aren't optional, they're essential. That’s why at Demesne Electrical, we supply solutions that go beyond compliance, empowering engineers and panel builders to build smarter, more connected systems.
One of our most trusted partners in this space is TELE Haase, an industry leader in intelligent monitoring and automation components. From load protection to digital performance sensors, the TELE range offers future-focused tools that streamline system diagnostics and improve long-term reliability.
A few pictures from our recent team day (& night!) in Dublin City. A great day where we welcomed some of the OEM Sweden team also.
We recently had an incredible team building day at Croke Park where we had inspirational talks from Mark Donovan and also Niall Breslin, who talked about the excellent work his charity A Lust For Life.
Our partners and friends from OEM Automatic AB Sweden attended also. Great to show them a piece of Irish history.
Thanks to all involved and also to our amazing team for their hard work and dedication 💪
Discover Klauke’s latest crimping innovations – the Micro Allrounder and i-press series. Compact, powerful, and built for real-world jobs, these tools are changing the way electricians and panel builders work.
We’re pleased to announce that, as of January 13th, 2022, Demesne Electrical has been acquired by OEM International, one of Europe’s leading technology trading groups. Headquartered in Sweden, OEM operates across 14 countries with 34 business units. The acquisition includes Demesne Electrical Sales Limited Ireland, and it’s important to note that there will be no changes to our day-to-day operations. This move strengthens our position in the market and opens the door to new opportunities as part of a larger international group.
PCE industrial plugs and sockets stand out for their Austrian-made quality, fast customisation, and broad product range. With ISO 9001:2015 certification and in-house production, PCE ensures consistent performance, safety, and quick turnaround times. Their excellent price-to-performance ratio makes them a reliable, cost-effective choice for demanding industrial applications.
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
My favourites | Articles | Cable length | Contacts | Operating temperature | PL | SIL | Weight | Price | |
---|---|---|---|---|---|---|---|---|---|
![]()
MMC-H Right 2M '2NC'
Art:
131101
Copied
|
2 m
|
2NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right 5M '2NC'
Art:
131102
Copied
|
5 m
|
2NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right 10M '2NC'
Art:
131103
Copied
|
10 m
|
2NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right QC M12 8way '2NC'
Art:
131104
Copied
|
0.25 m
|
2NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right 2M '2NC 1NO'
Art:
131105
Copied
|
2 m
|
2NC 1NO
|
-25° - 105°C
|
upp till Ple
|
upp till SIL3
|
220
|
| ||
![]()
MMC-H Right 5M '2NC 1NO'
Art:
131106
Copied
|
5 m
|
2NC 1NO
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right 10M '2NC 1NO'
Art:
131107
Copied
|
10 m
|
2NC 1NO
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right QC M12 8way '2NC 1NO'
Art:
131108
Copied
|
2 m
|
2NC 1NO
|
-25°C - 105°C
|
upp till Ple
|
upp till SIL3
|
140
|
| ||
![]()
MMC-H Right 2M '3NC'
Art:
131109
Copied
|
2 m
|
3NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right 5M '3NC'
Art:
131110
Copied
|
5 m
|
3NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right 10M '3NC'
Art:
131111
Copied
|
10 m
|
3NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Right QC M12 8way '3NC'
Art:
131112
Copied
|
0.25 m
|
3NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 2M '2NC'
Art:
131113
Copied
|
2 m
|
2NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 5M '2NC'
Art:
131114
Copied
|
5 m
|
2NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 10M '2NC'
Art:
131115
Copied
|
10 m
|
2NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left QC M12 8way '2NC'
Art:
131116
Copied
|
0.25 m
|
2NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 2M '2NC 1NO'
Art:
131117
Copied
|
2 m
|
2NC 1NO
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 5M '2NC 1NO'
Art:
131118
Copied
|
5 m
|
2NC 1NO
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 10M '2NC 1NO'
Art:
131119
Copied
|
10 m
|
2NC 1NO
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left QC M12 8way '2NC 1NO'
Art:
131120
Copied
|
0.25 m
|
2NC 1NO
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 2M '3NC'
Art:
131121
Copied
|
2 m
|
3NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 5M '3NC'
Art:
131122
Copied
|
5 m
|
3NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left 10M '3NC'
Art:
131123
Copied
|
10 m
|
3NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
| ||
![]()
MMC-H Left QC M12 8way '3NC'
Art:
131124
Copied
|
0.25 m
|
3NC
|
-25..105°C
|
e acc. ISO13849-1
|
3 acc. EN62061
|
|
|
Select a variant in the list
