DELTA/MEANWELL
Chrome Series Power Supplies - Single Phase
The Delta CHROME II series of single-phase DIN-rail power supplies delivers dependable and efficient DC output for control panels, machine enclosures, building automation systems, and more. Compatible with universal AC inputs, these units are built for industrial-grade reliability, compact installation, and energy efficiency
- Single-phase input (universal AC 85–264 V AC / 120–375 V DC) – Wide input range for flexible supply conditions
- Compact DIN-rail design – Ideal for panel installations in machines, automation systems and building controls
- High efficiency – Example 12 V DC / 100 W model achieves >86% efficiency. neumueller.com Class II double-insulation design – Low earth leakage current, no earth connection required for certain models.
Selected variant
Selected variant
Specifications
| Approvals | BSMI, CB, CCC, CE, UKCA, NEC Class 2, REACH, RoHS, TÜV, UL |
|---|---|
| Clamp type | Screw |
| Depth | 55 |
| Effect | 24 |
| Efficiency | 86.6 |
| Height | 87.5 |
| Hold-up time at 120 V AC, full load. Typical. | 14 |
| Hold-up time at 230 V AC, full load. Typical. | 70 |
| Input voltage AC | 100-240 V |
| Input voltage ac max | 264 |
| Input voltage ac min | 85 |
| Inrush current at 230 V ac typical | 40 |
| IP Class | IP20 |
| Material Protection | Plastic |
|---|---|
| Output Current | 2 |
| Output voltage | 12 |
| Output voltage max | 13.2 |
| Output voltage min | 10.8 |
| Power Consumption At 120 V AC | 0.7 |
| Power Consumption At 230 V AC | 0.5 |
| Supply Frequency | 50-60 Hz |
| Temperature Range Without Derating From | -30 |
| Temperature Range Without Derating To | 70 |
| Weight | 0.13 |
| Width | 35 |
Downloads
Product description
The Delta CHROME II series of single-phase DIN-rail power supplies delivers dependable and efficient DC output for control panels, machine enclosures, building automation systems, and more. Compatible with universal AC inputs, these units are built for industrial-grade reliability, compact installation, and energy efficiency
