Selected variant
Selected variant
Specifications
| Cable Connection | Screw |
|---|---|
| Cable Diameter Max | 6.6 |
| Cable Diameter Min | 3.3 |
| Coding | A |
| Cross-Section Max | 0.75 |
| Current max | 4 |
| IP Class | IP67 |
| LED indicator | No |
| Manufacturer Part No | 1200710038 |
| Number of poles | 4 |
|---|---|
| Shielded | No |
| Temperature range from | -25 |
| Temperature range to | 90 |
| Weight | 22.4 |
| Voltage AC max | 250 |
| Voltage DC max | 300 |
