CONTA-CLIP
Triple deck terminals - IKD 2.5mm²/VMAK
IKD, VMAK
- For connecting encoders or motor outputs
- Material polyamide 6.6
- Colour marked versions available
- Temperature resistance -40 ºC...+150 ºC
- Flammability class V2
Selected variant
Terminal Block IKD 2.5sq Triple Deck Beige
Art:
Selected variant
Specifications
| Additional information | with cross connection option |
|---|---|
| Approvals | CSA, CSA US, KEMA KUR, EAC |
| Color | Beige |
| Connections | 6 |
| Contamination degree | 3 |
| Country of origin | CZ |
| Cross connect channels | 3 |
| Cross section single wire from | 0.2 |
| Cross section single wire to | 4 |
| Cross section stranded wire from | 0.2 |
| Cross section stranded wire to | 4 |
| Cross section stranded with ferrule from | 0.2 |
| Cross section stranded with ferrule to | 2.5 |
| Cross-Section | 2.5 |
| CSA test standard | C22.2 No 158 |
| CSAus test standard | UL 1059 |
| EAC test standard | TR ZU 004/2011 |
| Flamklass | UL94-V2 |
| Height TS 32 | 62.8 |
| Height TS 35/7.5 | 58.3 |
| Insulation Material | Polyamide 6.6 |
| KEMA KEUR test standard | EN 60947-7-1:2009 |
| Length | 84.8 |
| Mounting | TS 35 |
|---|---|
| Number of levels | 3 |
| Operating temperature from | -40 |
| Operating temperature to | 105 |
| Overvoltage category | III |
| Pack Size | 50 |
| Plug gauge acc. EN 60 947-1 | A3 |
| Rated Current IEC | 24 |
| Rated impulse voltage | 4 |
| Rated wire cross section from (AWG) | 22 |
| Rated wire cross section to (AWG) | 14 |
| Rated Voltage IEC | 250 |
| Screw size | M 2,4 |
| Screw type | Slotted |
| Stripping Length | 7 |
| Tariff code | 85369010 |
| Torque max | 0.8 |
| Torque Min | 0.4 |
| Type of terminal | Screw Terminals, DIN Rail terminals |
| Weight | 17.18 |
| Width | 5 |
Product description
