CONTA-CLIP

Test-disconnect terminals PTK

Test-disconnect terminals are mostly used in the sectors of electricity generation and supply.They are tailored to the variety of switching demands for current-converter secondary circuits that predominate in these sectors. Current transformers must always have a secondary circuit when electricity meters and measuring instruments are being replaced, or when making comparative measurements.
  • Multi-foot TS35/TS32
  • Touch-safe to VBG 4
  • Dual function, disconnect & test

Selected variant

Avaible in several variants

Selected variant

Specifications

Approvals CSA, CSA US
Color Beige
Connections 2
Contamination degree 3
Country of origin DE
Cross connect channels 2
Cross section single wire from 0.2
Cross section single wire to 10
Cross section stranded wire from 0.2
Cross section stranded wire to 10
Cross section stranded with ferrule from 0.2
Cross section stranded with ferrule to 10
Cross-Section 10
CSA test standard C22.2 No 158
CSAus test standard UL 1059
Flamklass UL94-V2
Height TS 32 51.5
Height TS 35/7.5 47
Insulation Material Polyamide 6.6
Length 72
Mounting TS 35 and TS 32
Number of levels 1
Operating temperature from -40
Operating temperature to 105
Overvoltage category III
Pack Size 50
Plug gauge acc. EN 60 947-1 A5
Rated Current CSA 45
Rated current CSAus 45
Rated Current IEC 10
Rated impulse voltage 4
Rated wire cross section from (AWG) 8
Rated wire cross section to (AWG) 22
Rated voltage CSAus 600
Rated Voltage IEC 400
Screw size M 4
Screw type Slotted
Stripping Length 12
Tariff code 85369010
Torque max 2
Torque Min 1.2
Weight 24.66
Width 8
Voltage CSA 600

Product description

CONTA-CLIP test-disconnect terminals are available in the following three basic versions, each with or without a pre-assembled socket plug. All versions provide touch-safe protection according to DGUV-3. A captive, screw-on sliding partition is used to separate the current and voltage paths. The switch position is always easy to detect since the disconnect screw has a yellow insulating sleeve. In all versions, the STB 14/4 socket plugs can be used for a test pick-off for measuring values using the PS 4 test plug or the conventional (4 mm) insulated test plugs. The VH 19 connecting sleeves and the BS 25 screws or STB 14/4 socket plugs are required for fastening the QVS cross-switches above the terminal block. The cross-switches are available from 2 to 4 poles. The QSB internal cross-switches are positioned within the terminal block and make contact over the sliding contact on the LT- or QT-terminals. The cross-switches are available from 2 to 4 poles. The BS 25 mounting screws are used together with the VH 19 connecting sleeves to establish contact with the QVS cross-switches.
