AUER SIGNAL
Cubic Warning Light LED Series "A"
The Q series is a series of warning lights with modern LED technology or xenonstrobe, which has good signal strength and compact design. The unique lens gives a clear and bright light with good spread. LED technology offers long life, low power consumption and better durability in relation to vibrations.
- IP66
- LED / Xenon
- Can be combined with siren series "A"
Selected variant
Selected variant
Specifications
| Color House | Red |
|---|---|
| Color Lens | Red |
| Diameter | 94mm |
| Flash Frequency | 1.4 |
| IK Class | 9 |
| IP Class | IP66 |
| Light source | LED |
| Light type | Red LED |
| Mounting | Independent |
| Operating Voltage AC / DC Max | 24 |
| Sound control | Yes |
|---|---|
| Sound level max | 103 |
| Supply Voltage AC / DC Min | 24 |
| Temperature range from | -30 |
| Temperature range to | 60 |
| Terminal connection | 2.5 |
| Tone frequency max | 4600 |
| Tone frequency min | 500 |
Product description
And with IP66, these warning lights are suitable for industrial, fire, marine use, etc. The warning lights can be combined with other units of series A and Q.
